Baumann™ 51000 High-Pressure, Low-Flow Control Valve
Main Features
Features a compact size.
Suitable for sticky fluids and corrosive atmospheres.
Investment cast stainless steel body in 1/4 and 1/2 inch sizes or barstock N10276 nickel alloy. Other alloys available.
Class VI shutoff with soft seat available. Up to 207 barg (3000 psig) at 370° (1000°F).
Rugged bolted bonnet design.
Wide flow capacity range. Maximum rated Cv ranges from 0.00013 to 2.5 (0.0002 to 2.16 Kv).
Actuator is corrosion-resistant.
Available without positioner for fail open or fail close applications.
Specifications
Valve Size: NPS 1/4, NPS 1/2
Pressure Rating: 3000 psi CWP
Process Connection Type: Threaded
Material: Stainless Steel, Alloy
Other Configurations: Contact us for additional specifications or options.
Applications
Suitable for chemical/dye injection and acid/alkali solution control in industries such as paper production, textiles, specialty chemicals, and many others.
optimally designed for demanding low-flow, high-pressure control applications often found in laboratories and pilot plants
