Compact and light weight design reduces installed piping costs.
End connection options are available to meet your piping standards.
Dual stem and plug guiding provides increased stability during plug travel.
High quality S31600 stainless steel trim materials; S41600 stainless steel trim available.
Multiple trim capacity reductions available to meet changing process requirements.
FISHER FIELDVUE™ digital valve controllers are available for remote calibration and diagnostics in facilities utilizing the PlantWeb architecture.
The FIELDVUE DVC2000 digital valve controller has a local user interface that includes a liquid crystal display and four push buttons for menu navigation.
NOLEEK bellows bonnet and single through triple extension bonnets are available
Specifications
Valve Size: NPS 1/2 to NPS 3
Pressure ratings: ANSI CL300, NPS 3 CL150 only.
Process Connection Type: Threaded, Butt Welded
Material: Stainless Steel
Other Configurations: Contact us for additional specifications or options.
Applications
Mainly used in textile, pharmaceutical, tobacco, and food and beverage industries
Suitable for most fluid media, including water, steam, air, process gases, and more
Suitable for pressure, temperature, level and flow control
