• Connection Size: NPS 1/4, 1/2, 3/4, 1, 1-1/2, and 2
• Pressure Range: 0.14 to 25.9 bar / 2 to 375 psig
• Maximum Inlet Pressure: 27.6 bar / 400 psig
• Maximum withstand temperature 232°C / 450°F
• Maximum Flow Capacity: 3300 kg/h / 7300 lbs/h
• Operation Type: direct-operated
• Body Material:s Cast iron, steel, stainless steel, Hastelloy® C, and Monel®.

The MR98 series can be extensively applied in steam backpressure/pressure relief scenarios, such as power stations, heating and cooling systems, process systems etc. This series also offers options for differential pressure control and high-pressure configurations.
