Choose from square, keyed, or splined shaft connections.
The pressure-assisted seal design provides tight shutoff.
Trim and bolting materials are available for applications involving sour liquids and gases.
The valve body self-centers on the line flange bolts as a fast, accurate means of centering the valve in the pipeline.
Seal retainer screws are located so there is no interference with the sealing function of either flat sheet or spiral-wound line flange gaskets.
A feature of the valve design is that the torque necessary to open and close the valve is the same, regardless of the direction in which the differential pressure is applied.
Interchangeability of all parts, including shafts and disks, simplifies service and reduces maintenance costs.
Specifications
Valve sizes: NPS 3 to NPS 36, custom inlet/outlet, up to NPS 72
Pressure Rating: ANSI CL900-1500
Process connection type: Flanged, Single Flanged, Double Flanged, Lugged, Wafer
Material: Carbon Steel, Stainless, Alloy
Other configurations: Contact us for more additional specifications or options for this product
Applications
High-pressure angle travel valves are commonly used in the energy, power, oil and gas, petrochemical, chemical, and life sciences industries
Can be used with most fluid media, including water, steam, air, process gases, and more
Can be applied to noise suppression, cavitation, vapor conditions, erosive, low flow, corrosive, general service conditions, outgassing, flashing, etc.,
