The actuator/valve assembly action can be converted from push-down-to-open to push-down-to-close, or vice versa, without additional parts.
Both the metal and soft seal rings have pressure-assisting sealing action that ensures tight shutoff regardless of pressure drop.
Standard valve construction includes conductive packing to provide electrical bonding for hazardous area applications.
The valve will operate at elevated temperatures, with the appropriate trim components.
Additional travel indication can be achieved by using the indication line on the shaft, along with the disk position markings on the packing follower.
Redundant shaft retention provides added protection. The packing follower, anti-blowout ring, and shaft groove interact to hold the shaft securely in the valve body.
Specifications
Valve Size: NPS 2 to NPS 12
Pressure Rating: ANSI CL150-300
Process connection type: Flanged, Single Flanged, Double Flanged, Lugged, Wafer
Material: Carbon Steel, Stainless, Alloy
Other configurations: Contact us for more additional specifications or options for this product
Applications
Medium and low pressure angle stroke valves commonly used in the energy, power, oil and gas, petrochemical, chemical, life sciences and other industries
Can be used with most fluid media, including water, steam, air, process gases, and more
Can be applied to noise suppression, cavitation, vapor conditions, erosive, low flow, corrosive, general service conditions, outgassing, flashing, etc.,
