Excellent Flow Control–Precise contouring of the Vee-Ball provides a modified equal percentage flow characteristic.
Smooth Valve Operation–Precision machined parts, pressure-balanced seal, and low friction bearing designs allow smooth, precise movement of the ball.
Long Service Life–The durable HD metal seal construction provides long service life in demanding applications. The constant wiping action of the seal across the ball's sealing surface provides excellent service on high consistency fibrous slurry applications.
Line Centering Geometry–Cast or machined features on the body outside diameter align and center the valve within the mating pipeline flange bolting to ensure optimum performance.
Trim Versatility–The V200U drive train components are interchangeable with existing V150, V200, and V300 Series B valves. This feature allows you to reduce your spare parts inventory and maintenance procedures.
Specifications
Valve Size: NPS 3 to NPS 10
Pressure Rating: ANSI CL150-300
Process connection type: Flangeless
Material: CF8M/EN 1.4408 Dual Certified
Other configurations: Contact us for more additional specifications or options for this product.
