Available with flangeless or flanged body style for flexible installation.
The solid HD ball seal construction provides long service life in demanding applications.
Precise contouring of the Vee-Ball provides a modified equal percentage flow characteristic.
Materials are available for applications involving sour liquids and gases. These constructions comply with NACE MR0175-2002, MR0175-2003, MR0103, and MR0175/ISO 15156.
Ball seal inspection and replacement is done at the valve body inlet, without removing the actuator or disassembling the valve.
The one-piece valve body improves structural integrity of the pressure boundary by eliminating leak paths that could be caused by the gaskets in two-piece, bolted valve designs.
The optional ENVIRO-SEAL™ packing systems are designed with very smooth shaft surfaces and live loading to provide sealing capability.
Specifications
Valve Size: NPS 1 to NPS 10
Pressure Rating: ANSI CL600
Process connection type: flanged
Material: Carbon Steel, Stainless, Duplex, Alloy
Other configurations: Contact us for more additional specifications or options for this product.
Applications
Low-pressure rotary valves commonly used in power plant, petrochemical, chemical, paper and other industries
Can be used with most fluid media, including water, steam, air, process gases, etc
For fibrous fluids, V-ball valves have a shearing, self-cleaning effect
