Equal percentage flow characteristic— An equal percentage flow characteristic provides an improved throttling range comparable to that of a segmented ball valve. This improved capability allows you to control closer to the target set point, regardless of process disturbances, which results in a reduction in process variability.
Eccentric design: Eccentric rotation of the butterfly plate provides greater closing capability and a larger contact area with the valve seat, contributing to improved sealing performance.
PEEK/PTFE bearings: As standard, this bearing material offers low friction and high wear resistance for high pressure drop and low maintenance applications.
Interchangeable sealing technology: Soft or metal seals can be used on the same valve body, providing flexibility and easy maintenance options.
Recessed bearing design: facilitates quick and easy maintenance and replacement without disassembling other parts of the pipe or valve.
Soft Seal or Metal Seal Options: Valves are available with both soft seal and metal seal options to suit different applications. Soft seals are typically used for general chemical and industrial applications, while metal seals are suitable for Servere Sevice.
Specifications
Valve Size:NPS 2~24
Pressure rating: ASME B16.5 CL150-600 PN10-PN40
End Connection Styles: Lugged, double-flange type, Wafer and other types of connection to adapt to different installation environments
Materials: WCC, LCC, CF8M, etc
Other configurations: Contact us for more information.
Applications
Can be used in the hydrocarbon industry, the refining industry, the chemical industry, the paper and pulp industry, the metallurgical industry, the mining industry, and other industries that require precise control of fluids.
