The seat ring design self-centers, self-laps, and dynamically aligns with V-notch ball, giving superior cycle life.
No special orientation, precision clamping, or repetitive centering of V-notch ball and seat ring is required when tightening the retainer, promoting accurate alignment and easy assembly.
Precise contouring of V-notch ball provides a modified equal percentage flow characteristic.
Unrestricted, straight-through, flow design provides greater capacity than many conventional globe and rotary eccentric plug valves.
Integral valve flanges mate with many different classes of pipeline flanges, satisfying a variety of piping requirements.
The V-notch ball cams into and out of the seat minimizing contact with the seat ring for reduced wear and friction.
Specifications
Valve Size: NPS 3 to NPS 12
Pressure Rating: ANSI CL125-600
Process connection type: flanged
Material: Carbon Steel, Stainless, Alloy
Other configurations: Contact us for more additional specifications or options for this product
Applications
Valves for severe working conditions in the oil refining, petrochemical, chemical and other industries
Can be used with most fluid media, including water, steam, air, process gases, etc
Good abrasion resistance for particles and severe working conditions
