UNIVALS SFBO Tank Bottom Valve

Main Features

The valve body is of integral Y-shape structure, the channel adopts streamlined design without dead angle, and do sandblasting or polishing treatment to reduce pressure drop loss
The sealing surface is surfaced or sprayed with hard alloy to extend the service life of the valve
Spool self-centering characteristic, reliable sealing performance
Seat conical structure, in order to ensure the sealing at the same time to prevent the media residue
Bolt + butterfly spring dynamic load structure, so that the packing in the temperature, pressure changes still ensure good sealing performance

Specifications

Type:Upward Spreading Kettle Bottom Valve Downward Spreading Kettle Bottom Valve, Kettle Bottom Ball Valve
Valve Size: NPS 1/2 to NPS 14
Pressure Rating:Class 150~Class 300
End connections: flange, butt welding
Material: carbon steel, alloy steel, stainless steel
Other Configurations:Contact us for more information on technical specifications or options for this product

Applications

Mainly used in the bottom of all kinds of storage containers, can also provide non-standard design products according to the user's special requirements.
